2024 LSAA Design Awards Entry - #5000 Narre Warren Metro Station- Cable Truss Ceiling Support
IDENTIFICATION NUMBER 5000
ENTRY CATEGORY (1-6) 5 Special Applications
ENTRANT ROLE Specialist D&C Subcontractor
PROJECT NAME: Narre Warren Metro Station- Cable Truss Ceiling Support
APPLICATION OF PROJECT: Cable Bow truss and secondary framing supporting ceiling and PID screen.
PROJECT DESCRIPTION:
How 3 Tons of Steel & Cable Replaced 30 Tons of Structural Steel: A New Era in Sustainable Infrastructure
On March 28th, 2024, the newly reconstructed metro stop at Narre Warren station, a critical junction on Melbourne’s Pakenham Line, was officially opened to the public. This station, one of the busiest along the line, had long been plagued by a hazardous and congested rail-road crossing. The recent rebuild of Narre Warren Station, now elevated above the streets in a sleek skyline crossing, is a significant achievement in the city’s ambitious Level Crossing Removal initiative.
The redesign of Narre Warren Station not only addresses the critical safety and congestion issues but also introduces a groundbreaking structural innovation that sets a new benchmark for urban infrastructure projects. Originally, the station's ceiling was to be supported by pairs of 800mm deep welded Universal Beams, each spanning 25 meters between substantial crossheads.
PROJECT NAME: National Throws Centre of Excellence
PROJECT DESCRIPTION:
Fabritecture was contracted for the design and construction of a Serge Ferrari TX30 throws run up canopy for the State Athletics Facility at the Queensland Sports and Athletics Centre (QSAC) in Nathan, Queensland. The tensile building was built to house discus and hammer throwing. The result is a stunning and functional canopy that enhances the sports complex and provides a world-class facility for athletes to train and compete in.
2022 LSAA Design Awards Entry #0857 M Pavilion
IDENTIFICATION NUMBER 0857
PROJECT SIZE External mesh = 370 sqm. STFE Layer = 170 sqm. Waffle roof layer = 400 sqm
ENTRANT ROLE Designer/Engineer
PROJECT NAME: M Pavilion 2022
APPLICATION OF PROJECT:
The project is the 9th installation of MPavilion (an initiative of the Naomi Milgrom Foundation) in Kings Domain, Melbourne.
The MPavilion 2022 season of free events features hundreds of local and international collaborators, spanning talks, workshops, performances, kid friendly experiences and community projects. Designed as both a temporary summer pavilion and an enduring architectural creation. At the end of the season MPavilion 2022 has been gifted to the people of Victoria and moved to a permanent home (RMIT Brunswick campus) to be engaged by the community in perpetuity, adding to the ongoing legacy and impact of the MPavilion project.
IDENTIFICATION NUMBER 5874
ENTRY CATEGORY (1-6) 5 Special Applications
ENTRANT ROLE: Fabricator
PROJECT NAME: Metro Sports Facility
APPLICATION OF PROJECT: Interior acoustic membrane
PROJECT DESCRIPTION:
Fabric Structures was instrumental in the development of the Metro Sports Facility in Christchurch, focusing on the design, engineering, procurement, and installation of a custom ceiling panel solution for the aquatic center. Our task was to create a ceiling system with dual functionalities: an acoustic layer on the underside facing the pools to absorb sound and reduce echo, and a solid membrane on the top side to support the plenum area above. We worked closely with architects and engineers to ensure the panels met both aesthetic and functional requirements. Our precise engineering and installation processes delivered a high-quality solution that enhanced the acoustic environment while maintaining structural integrity. This project showcases our capability to provide innovative fabric solutions tailored to complex needs, contributing significantly to the Metro Sports Facility’s role as a leading sports and recreation venue in Christchurch.
APPLICATION OF PROJECT:
Swimming pool retractable shade cover
PROJECT DESCRIPTION:
Challenged to create an innovative retractable roof for the swimming pool in the new sports precinct development for St Margaret’s Anglican School in Brisbane, Australia, we designed, engineered, developed, tested, fabricated and installed the Velarium Variable Shade System.
The Velarium shade system developed for St Margaret’s is an advanced motorised retractable shade system. This variable shade system is created using opposing sets of architectural-grade PVC mesh shade panels, supported on a cable grid that spans freely across the width of a pool. The Velarium system allows for large spans to be covered with minimal visible structural elements above the pool.
The system can be operated directly from a master control panel or a remote hand control. Each Velarium shade section is retracted and deployed by an independent motor, giving the operator the flexibility to open or close individual panel sections to suit their requirements. This clever design allows for panels to be deployed in almost any position between fully open and fully closed, and can be controlled by a single person.
DESIGN / FABRICATION / INSTALLATION BRIEF
Blight Rayner Architects initially approached us with a challenge to design and develop a retractable roof concept for the swimming pool in the new sports precinct development at St Margaret’s Anglican School in Brisbane.
Application: Innovative architectural alternative to Safety Hoarding for the construction industry
Project entered in the LSAA 2018 Design Awards (Cat 7 Special Applications, #7700)
PROJECT DESCRIPTION:
The Dual-Skin Safety Netting Structure made from tensioned fabric is changing the way the construction Industry looks at traditional hoarding and safety nets.
Using architectural fabrics and tension membrane engineering outside the square to provide aesthetic cost saving safety control measures.
By providing a safety net structure that could protect the public from the works above saved the client almost $1 million in overtime costs when they would usually be working a night. This solution provided the client the ability to work during the day without closing down the area with the exclusion zones. Prior to the solution, the client could only do these works at nighttime as this project is in one of the largest high-rise buildings in the Sydney CBD.
LSAA 2018 Design Awards HIGH COMMENDATION - Category 7 Special Applications (7627)
Application: Art Architecture Installation
PROJECT DESCRIPTION:
Subjects of continual exploration in the work of, portals to frame views and establish connections between buildings and their context. This project extends this function further - a calibrated device and a long lens between Venice and Australia. Looking through these portals will introduce the viewer to the buildings of John Wardle Architects, landscapes of Australia, and the craft of several collaborators that were central to realising the work.
This project was entered in the LSAA 2018 Design Awards (Cat7 Special Applications, #7432)
Application: Cable-net arbour walkway incorporating artwork panels, vines & foliage and feature lighting, linking the New Perth Stadium with the parklands precinct and the main transport infrastructure hubs of Swan River Pedestrian Bridge and the Stadium Train Station.
PROJECT DESCRIPTION:
A 350m long architectural tensioned cable-net structure, supporting indigenous inspired artwork panels, crawling vines and plants and feature programmable LED lighting. The Arbour walkway was designed to guide the major pedestrian flows on game day from the main transport hubs at either side of the stadium precinct. The cable-net structure snakes around half of the stadium and is supported by bespoke steel arches with tapered bases. In total over 3,500 artwork panels, perforated with designs inspired by local indigenous groups, are supported by nearly 15km of stainless steel cables and clamps. At the bases of the arches, vines and crawling plants grow from garden beds and in time will rise up and over the precinct pathways below.
Application: Architectural and functional shade provision for the rooftop of an iconic cubic wine-tasting building at D’Arenberg Winery SA.
PROJECT DESCRIPTION:
Design, fabrication and installation of a world-first collection of 16 x 5 metre multi-coloured architectural and functional umbrellas providing patterned shade over the roof of an iconic “cubic” wine-tasting pavilion at the D’Arenberg Winery in McLaren Vale, South Australia. The “mary-poppins” styled umbrellas were required to be supplied with an automatic opening function to assist in reducing building heat load; and also to automatically close during in high wind. The retraction system needed to not only to close the umbrellas, but to also lay them fully flat on the cube’s roof.
LSAA 2018 Design Awards AWARD OF EXCELLENCE - Category 7 Special Applications (7235)
APPLICATION OF PROJECT:7235)
Application: Custom Lightweight Architectural Structure with aluminium cladding
PROJECT DESCRIPTION:
As part of the Westfield Chermside AUD$355 million redevelopment, we were contracted for the fabrication and construction of a large scale custom aluminium retail structure, and subsequently, a porte cochère entry structure. The aluminium structure is called the ‘Urchin’ as the distinctive shape resembles the round, jagged edges of a sea urchin. The design intent behind the structure was to create a main focal area for the redevelopment and a “meeting point” for the centre. The area below the Urchin is used for events and entertainment, thanks to its amazing programable LED lighting system integration. The Urchin is our first large architectural structure that does not include any fabric.
Images Copyright Steve Ryan, Rix Ryan Photography
LSAA 2011 Design Awards Entry (Cat 7, 7001) Trailfinders Australian Garden - Chelsea Flower Show
PROJECT DESCRIPTION
MakMax’s client, Flemings Nurseries exhibits annually at the Royal Horticultural Society’s Chelsea Flower Show, one of the world most prestigious social and horticultural events. Fleming’s often win awards for their unique exhibition stands. MakMax was engaged to bring an architect’s design to life in the form of a unique temporary structure for Fleming’s entry at the 2011 RHS Chelsea Flower Show.
Entry for LSAA 2007 Design Awards
Award of Excellence (Special Applications)
Counter Observation Barrier Screen - Counter Terrorist
Entrant: Alfresco Shade (Entry #4229)
Client: SAAB Barracuda Australia
Structural Engineer: Ian Norrie (Bond James Norrie), John Williams (Hughes Truman)
Specialist Consultant(s): SAAB Sweden Builder: Alfresco Shade Fabricator(s): Alfresco Shade
Application and Function
Modern high speed mechanized arrnies are very hard to hit and are able to resist most low tech weapons of the gorilla armies but the minute they stop surprise attacks on static troops and vehicle produces high casualties. A deployable defensive screen evolved out of the need to protect stationary command posts and high value soft targets from sneak attacks.
