This project was entered in the LSAA 2007 Design Awards (#3197) "Medium Fabric Structures"

Entrant: Tattersall Engineering

Client: Aquinas College / J A Dodd     Architect: Designinc Adelaide (Geof Naim)
Structural Engineer: Tattersall Engineering (See SEMF 2015)
Specialist Consultant(s): Wade Consultants     Builder: Tecraft Pty Ltd
Fabricator(s): Horizon Sailmakers / C E Bartlett, Riband (Steel), A Noble & Son (Cables)

Application and Functions of the New Aquinas College Forum Structure

The structure is a pivotal element in an $8m redevelopment of the main Aquinas College campus, which comprised a new library, Year 9 centre, canteen and arts centre as well as refurbishment of the old library as an IT, arts and careers centre.

Credits - Entered by MakMax

Category: Tension structures - (coated fabrics) less than 500sqm
Client: W. Eggerking & Co Pty Ltd
Engineer: Tensys, Peter Lim
Fabric: Hiraoka 212-II SAC
Date completed: 21 February 2012
Address: 60 Margaret Street, Sydney NSW 2000
Size: 600sqm
Steel Supplier: Steelman
Fabric Supplier: Hiraoka Australia
Installer: Sydrig

Covering an area surrounded by buildings and infrastructure can be challenging, this project succeeds in proving 300sqm of covered space to a Sydney inner city child care centre. Our client requested a complete coverage solution to an odd shaped terrace area in Sydney’s inner city.

ID NUMBER  2284
ENTRY CATEGORY    2 – Medium structures
ENTRANT ROLE    Designer / Installer
PROJECT NAME: MSU John Goodman Amphitheatre
APPLICATION:       Amphitheatre canopy

PROJECT DESCRIPTION: MSU John Goodman Amphitheatre

The MSU John Goodman Amphitheatre stands as a testament to innovative design meeting environmental challenges. Covering 6,792 square feet, and constructed with PVC TX30 material for durability and weather resistance, it offers exceptional acoustics and a versatile venue for concerts, plays, lectures, and cultural events, ensuring a premier outdoor experience for performers and audiences alike.

Sydney Aquarium Dugong's at Mermaid Lagoon

This Project was entered into the LSAA 2009 Design Awards (29047)Entrant: UFS Australasia Pty Ltd - Designer / Fabricator
Location: Sydney Aquarium - Darling Harbour Sydney
Client: Sydney Attractions Group
Struct. Eng.: Wade Consulting
Builder: Universal Fabric Structures / Ozrig
Fabricator: Fabric Shelter Systems

No further details have been entered.

This project was entered in the LSAA 2011 Design Awards (Cat 2, 2575)

PROJECT DESCRIPTION

In total three structures with a combined coverage of 1930m2.  The project consisted of two identical shade cloth structures comprising of eight Monotech HDPE 370 shade sails, 806m2 in plan area. The third structure of similar design comprised of six main sails of Fibertop PTFE and two hypar decorative sails in Monotech HDPE 370, 318m2 in plan area. The requirement for the project was an Iconic Design providing Solar Shading to shelter play equipment and BBQ facilities.

OTHER IMAGES

This project was entered in the LSAA 2009 Design Awards (Cat 2, #2066)

Entrant: Tensys Engineers Pty Ltd
Location: Las Vegas, USA

Description of the Tensile Roof to the APM in Las Vegas

The tensile fabric roof (approximately 10,000 sq ft) each covers the APM station at Monte Carlo and Bellagio Casino/Resort.  The APM stations are part of the US7 billion dollar development in Las Vegas (designed by Gensler LA) due for opening in various stages the end of 2009.
