LSAA 2007 Design Award Entry (Cat 3, 3002)

Entrant: Taiyo Membrane Corp (Later as MakMax in Australia)

Client: Major Projects Australia      Architect: Peddle Thorpe Architects
Structural Engineer: Xiang Du (TMC) & Connell Mott McDonald
Specialist Consultant(s): Connell Wagner (steel design)
Builder: John Holland Pty Ltd

Application and Function:

Designed to be suitable both during and after major events, the roof has been designed in two sections.
Section one is a permanent roof made from PTFE fabric.  This roof covers the pool as well as stadium seating for 3,000 spectators.  Section two extends the roof for “Commonwealth Games” mode.
Two temporary PVC roofs are erected either side of the permanent roof to cover a further 8,000 seats. The temporary structures create a festive effect with their high pitches and large sloping support columns.

This project was entered in the LSAA 2018 Design Awards (Cat 4 Large Fabric Structures, #4432) by MakMax

Application: Cover over 3 adjacent bowling greens at the Playford City Bowls club, South Australia.

PROJECT DESCRIPTION:

The design, fabrication and installation of the largest tensile membrane canopy structure over a bowling green in the Southern Hemisphere. The 5300m2 PVC (Mehler FR900N) structure covers a total of 21 rinks (120m length), lit with state of the art LED sports lighting, allowing year round utilization of the bowling green’s irrespective of the weather conditions. In addition to bowls, the venue is also used to host corporate and social events.

LSAA 2011 Design Award Entry (4210)

APPLICATION OF PROJECT:

Canopy shade structure: The architectural PTFE membrane canopy provides weather protection for an outdoor events plaza and exterior walkway.

PROJECT DESCRIPTION

A truly stunning piece of fabric architecture was created with this stunning lightweight membrane roof at ITE College (West) in Singapore. Supported only by a complex cable system and large steel wall plates bolted to 4 different buildings, the 3000m2 PTFE Canopy provides shelter to the Events Plaza and exterior walkways below spanning an incredible 75m span in one direction and 45m in the other.

Entered into the LSAA Design Awards 2007 (Large Structures, 3195)

Entrant: Oasis Tension Structures
Client: Multiplex Constructions (Vic) Pty Ltd
Architect: Darryl Jackson Pty Ltd
Structural Engineer: Tensys
Specialist Consultant(s): Drafting Steel One
Builder: Oasis Tension Structures (Australia) Pty Ltd
Fabricator(s): Atkins Fabrications Pty Ltd Structurflex NZ,
Geelong Fabrications, Ronstan

Aside from the images below, no other details have been entered for this project.

APPLICATION OF PROJECT:

This project was one spearheaded by HRH Dr Sheik Sultan Bin Mohammed Al Qasimi (Ruler of Shajah) and was kept under wraps for the past 4 years.  The Birds of Africa Aviary forms the centre piece of the Safari and highlights the flamingo habitat.

PROJECT DESCRIPTION:

A bird aviary comprising 10,000 sqm of stainless steel woven cable mesh together with shading panels.

DESIGN / FABRICATION / INSTALLATION BRIEF

The function requirement was to create a stainless steel mesh bird aviary to both keep the birds in, as well as keep out unwanted pests.  Due to the hot summer months in the Middle East an additional shading element was required. This has both a functional brief as well as providing both texture and difference in translucency to the aviary structure

STRUCTURAL SYSTEMS

A tensile anticlastic form created with structural steel and cable system.  The tension element is in the form of stainless steel cables and mesh together with PVC/PES shading elements.

MATERIALS

Structural architectural steel

Stainless woven cable mesh

PVC/PES fabric

Entrant: MakMax Australia

• Category: 4 ID Number:  4301

• Location: Fairfield Rd, Cabramatta NSW

• Client: Paynter Dixon Constructions Pty Ltd

• Completion Date: October 2011

APPLICATION OF PROJECT: Long span sporting arena roof.

PROJECT DESCRIPTION:

Sun safety in sport is a growing concern across all sectors of our community. Providing a playing surface protected from harmful sun is vital to the continuity of some sports. The sport of lawn bowls in particular have realised this is especially true for their aging demographic and shrinking membership.

LSAA 2011 Design Award Entry (Category 4): Panoli Gate House - India

PROJECT DESCRIPTION

As a flagship development in the area Panoli needed a striking and unique entrance. MakMax’s Indian office was able to provide a prominent entrance structure to suit. The project, Panoli Gate House presented a new challenge for MakMax engineers. The large 1,300 sqm area required shade, weather protection, as well as a plan for collecting run off. Inspired by the design and functionality of the St Tropez products MakMax already produces as standard products, engineers decided to replicate this shape and function on a grand scale.

Application: Sports stadium on top of a multi-level car park

This project was entered in the LSAA 2018 Design Awards (Cat 4 Large Fabric Structures, #4066)

PROJECT DESCRIPTION:

The Queensland University of Technology (QUT) Sportsfield Car Park project was part of the construction of a $27 million multi-story car park at the QUT Kelvin Grove campus in Brisbane. The roof-level is home to a FIFA accredited sports field, developed as part of the long-term expansion plans for the University.

The Queensland University of Technology (QUT) Sportsfield Car Park features a FIFA-accredited sports field on the roof of the AUD$27 million multi-level car park. This unique project included the design and construction of the steel, PTFE fabric membrane, fall arrest mesh, static line and score board.

2024 LSAA Design Awards Entry #4866 Link at Langley

PROJECT DESCRIPTION:

The Link@Langley ETFE Atrium not only enhances the visual appeal of the riverside redevelopment but also demonstrates the successful fusion of modern lightweight glazed roof design with practical engineering solutions.

The result is a harmonious blend of form and function and a symbol of innovation, seamlessly integrating into its surroundings while offering a captivating architectural aesthetic. This project exemplifies the power of clever design and cutting-edge materials in shaping the future of urban architecture. Massive in size and scope, the Link@Langley ETFE Atrium structure is 65 meters long and 40 metres wide and sits atop a former office building between seven and eight storeys above the atrium floor.

Entrant: Light Weight Structures

• Location: Neath Street Cessnock NSW

• Client: East Cessnock Bowls Club

• Completion Date: September 2012

APPLICATION OF PROJECT:

The project covered one Bowling Green measuring 1820 sqmts. The project was designed to offer weather protection to bowlers, including night time use of the Bowling Green (in a residential setting) and minimal cleaning maintenance over the life of the structure.

APPLICATION OF PROJECT

Airport terminal drop off area roof

The New Yogyakarta International Airport (NYIA) Description

The new Yogyakarta International Airport (NYIA) at Kulon Progo Regency, serves the Yogyakarta Special Region, Indonesia, and is operated by Ankasa Pura. As part of the airport development, Fabritecture was contracted for the design & supply of ETFE pneumatic roofing as well as supply system and ducting.

The ETFE component of the roof comprises 84 2-layer cushions covers a plan area of approximately 14,314m² and is part of an overall canopy integrating polycarbonate elements also, overall providing 18,900m² of weather cover the exterior drop-off area.
