In terms of our LSAA Design Awards, a Medium sized Fabric Structure, or tensioned membrane structure) would have a surface area of between 250 and 1000 sqm.

Fabric or membrane structures of this size are often of one geometric form such as a conical structure with a central bale ring attached to a mast or tied down. The perimeter could be a series of edge cables, trusses or beams. If multiple units are used they the final structure may fall into the "large" category.

Other forms could be panels with internal diagonal arches, crossed arches, barrel vaults with intermediate valley cables.

The following articles are in random order whilst the List of Medium Structures is in order of most recently modified article first:

Glen Eira Aquatic Centre
Glen Eira Aquatic Centre



LSAA 2013 Design Awards - High Commendation (Category 2 Medium Structures #2926)

Entrant: Oasis Tension Structures

  • Location: East Boundary Rd, East Bentleigh

  • Client: Glen Eira City Council; Completion Date: December 2011

Judges Comments:

"Advances the technology in insulated membranes"

"Rather idiosyncratic form which answers a functional challenge, has a bit of fun, and provides some identity to a facility not short of disparate elements"

2926E02
2926E01
2926E11
2926E10
2926E09
2926E08
2926E07
2926E06
2926E05
2926E04
2926E03

Yas Island Gateway Park
Yas Island - Gateway Park



This project was entered in the LSAA 2011 Design Awards (Cat 2, 2575)

PROJECT DESCRIPTION

In total three structures with a combined coverage of 1930m2.  The project consisted of two identical shade cloth structures comprising of eight Monotech HDPE 370 shade sails, 806m2 in plan area. The third structure of similar design comprised of six main sails of Fibertop PTFE and two hypar decorative sails in Monotech HDPE 370, 318m2 in plan area. The requirement for the project was an Iconic Design providing Solar Shading to shelter play equipment and BBQ facilities.

OTHER IMAGES

2011257509
2011257508
2011257501
2011257500

Abilene Airport
Abilene Airport



Entrant: Atkins Fabrication (Aust) Pty Ltd - Fabricator
Location: Abilene - Texas USA
Client: USA Shade & Fabric Structures Inc.
Fabricator: Atkins Fabrication (Australia) Pty Ltd

This project was entered in the LSAA 2009 Design Awards - Medium Structures (#2129)

No further details have been entered at this stage.

LSAADA2009212903
LSAADA2009212902
LSAADA2009212901

St Joseph's College Netball Court
St Joseph's College Netball Court



Project entered into the LSAA 2016 Design Awards (Medium Fabric Structures Entry 2698)

Entrant: Structureflex (Designer / Engineer)

Location: Echuca, Victoria. Completed: January 2015
Client: St Joseph's Catholic College
Team: Y2 Architects, Steve Huppert, John Killmister (Cert. Eng), Shade Living Pty Ltd, Fabric Solutions (membrane), Thornton Engineering (steel)

Application

As part of a new gymnasium and music centre it was proposed to extend a covered outdoor area over the new netball court that adjoins the building with a 38m x 22m PVC barrel arch roof structure attached to new steel framed gymnasium.

LSAADA2016Cat20164
LSAADA2016Cat20162
LSAADA2016Cat20163
LSAADA2016Cat20160
LSAADA2016Cat20161

60 Margaret Street, Sydney
60 Margaret Street, Sydney (MakMax)



Credits - Entered by MakMax

Category: Tension structures - (coated fabrics) less than 500sqm
Client: W. Eggerking & Co Pty Ltd
Engineer: Tensys, Peter Lim
Fabric: Hiraoka 212-II SAC
Date completed: 21 February 2012
Address: 60 Margaret Street, Sydney NSW 2000
Size: 600sqm
Steel Supplier: Steelman
Fabric Supplier: Hiraoka Australia
Installer: Sydrig

60marg3
60marg4
60marg2
60marg1
60mar5

Jakarta ETFE Canopy
Jakarta ETFE Canopy



Jakarta ETFE Canopy

Entrant: Fabritecture (Designer and Installer)

Location: Jakarta, Indonesia.   Completed: June 2015  Client: Leightons Asia
Team: Denton Corker Marshall, Maffeis Engineering, Fabritecture, Seele Covertex

Application: ‘Floating’ canopy suspended over a courtyard using a 2-layer ETFE cushion system, supported exclusively by stainless steel tie rods

This project was entered in the LSAA 2016 Design Awards (Medium Fabric Structures, 8128)

LSAADA2016Cat20175
LSAADA2016Cat20174
LSAADA2016Cat20173
LSAADA2016Cat20172
LSAADA2016Cat20171
LSAADA2016Cat20190
LSAADA2016Cat20189
LSAADA2016Cat20187
LSAADA2016Cat20188
LSAADA2016Cat20186
LSAADA2016Cat20185
LSAADA2016Cat20184
LSAADA2016Cat20183
LSAADA2016Cat20181
LSAADA2016Cat20182
LSAADA2016Cat20180
LSAADA2016Cat20179
LSAADA2016Cat20178
LSAADA2016Cat20177
LSAADA2016Cat20176

Green School Pods, New Plymouth, NZ
Green School - New Plymouth, NZ (2021 DA Entry)

APPLICATION OF PROJECT:

3 Pod like classrooms at Green School NZ

PROJECT DESCRIPTION:

To provide an outer skin from a material that can be recycled if/when replaced and also blends into environment.  Wastage of non-recyclable materials to be kept to a minimum.

Also to provide the support frame to take the PVC membrane.

DESIGN / FABRICATION / INSTALLATION BRIEF

It was requested by the architect that we would supply a membrane solution for three-pod like classrooms for Green School New Zealand, to function as an aesthetic cladding and to create a ventilated thermal barrier to reduce a “heat soak effect” into the building.  This was to complement the “green” label for the structure, reducing running costs and adding an organic look.

Dubai Outlet Mall Entrance Dome
Dubai Outlet Mall Entrance Dome



Entrant: Structurflex Ltd

Client: Emirates Engineering Services    Architect: ARENCO
Structural Engineer: Wade Consulting Group
Fabricator(s): Structurflex Ltd

This project was entered in the LSAA 2007 Design Awards (Medium Structures #3022)

Application and Function

Provide an ascetically pleasing entrance structure that is visible from a great distance.
The instruction was to supply an open and light atrium at the entrance to the mall.

LSAADA20073022scana
LSAADA20073022scanc
LSAADA20073022c
LSAADA20073022a
LSAADA20073022scane
LSAADA20073022scand

Interior shot of the Dreamworld Switchback canopy
Interior shot of the Dreamworld Switchback canopy

Dreamworld Taipan Theme Park Entrance Canopy Description

The Steel Taipan ride at Dreamworld on the Gold Coast is the theme parks newest attraction. The AUD$32million roller coaster features a 1.2km track roller coaster and the Southern Hemisphere’s first triple launch system that launches the train forward, backwards, and then forwards again at a top speed of 105km/hr!

Fabritecture was contracted for the design & construction of a bespoke walkway canopy structure to shelter patrons as they wait in line for the Steel Taipan ride. The structure features custom printed Serge Ferrari PVC designed to match the architectural intent of the structure – to emulate the scales of a taipan snake!

Great Southern Oceans
Great Southern Oceans



Entrant: Architectural Sails

Client Zoological Parks Board of New South Wales
Architect: Jackson Teece Architects
Structural Engineer: Hughes Trueman (Concept Design)
Specialist Consultant(s): Wade Consulting Group, Meinhardt
Fabricator(s): Architectural Sails

This project was entered in the LSAA 2007 Design Awards (Cat 2, Medium Fabric Structures #2469)

Aside from the images, no further details have been entered at this stage.

LSAADA200724690088
LSAADA200724690086
LSAADA200724690084
LSAADA200724690081
LSAADA200724690083
LSAADA200724690080
LSAADA200724690079
LSAADA200724690077
LSAADA200724690073
LSAADA200724690076
LSAADA200724690072
LSAADA200724690071
LSAADA200724690070
LSAADA200724690069
LSAADA200724690059
LSAADA200724690057
LSAADA200724690038
LSAADA200724690116
LSAADA200724690108
LSAADA200724690115
LSAADA200724690104
LSAADA200724690100
LSAADA200724690099
LSAADA200724690096
LSAADA200724690095
LSAADA200724690093
LSAADA200724690092
LSAADA200724690089
LSAADA200724690090

Aquinas College Forum
Aquinas College Forum



This project was entered in the LSAA 2007 Design Awards (#3197) "Medium Fabric Structures"

Entrant: Tattersall Engineering

Client: Aquinas College / J A Dodd     Architect: Designinc Adelaide (Geof Naim)
Structural Engineer: Tattersall Engineering (See SEMF 2015)
Specialist Consultant(s): Wade Consultants     Builder: Tecraft Pty Ltd
Fabricator(s): Horizon Sailmakers / C E Bartlett, Riband (Steel), A Noble & Son (Cables)

Application and Function(s) of Project:

The structure is a pivotal element in an $8m redevelopment of the main Aquinas College campus, which comprised a new library, Year 9 centre, canteen and arts centre as well as refurbishment of the old library as an IT, arts and careers centre. The Forum structure links and protects all the adjoining buildings, proving a substantial undercover area in the middle of the school which serves as a protected function centre, meals and play area, incorporates a stage with a protected auditorium area, and links with the existing gymnasium and sports centre building.

LSAADA2007319750
LSAADA200731975897
LSAADA200731975895
LSAADA200731975893
LSAADA200731975889
LSAADA200731975886
LSAADA200731975161
LSAADA200731973213
LSAADA200731973208
LSAADA2007319759
LSAADA2007319758
LSAADA2007319757
LSAADA2007319756
LSAADA2007319755
LSAADA2007319752
LSAADA2007319749
LSAADA2007319748
LSAADA2007319745
LSAADA2007319744
LSAADA20073197nightpanorama

Hagley Oval from pitch
Hagley Oval from pitch



Project entered in the LSAA 2016 Design Awards (Medium Structures, #4047)

Entrant: Fabric Structure Systems (Designer / Fabricator / Installer)

Location: Christchurch, New Zealand.   Completed: October 2014  Client: Cantebury Cricket Association

Team: Athfield Architects, Wade Design Engineers Ltd, Southbase, Fabric Structure Systems

Application: The establishment of an international venue at Hagley Oval for the 2015 cricket world cup and beyond. This required the construction of a new world class cricket pavilion, out of which an architectural fabric was chosen.

3-Hagley-view-along-seating
6-Hagley-SIDE
5-Hagley-Internal-Mast
4-Hagley-view-under-canopy-from-pitch
2-Hagley-long-view-to-canopy
1-Hagley-view-from-pitch-centre

CityCentre Automated People Mover
CityCentre Automated People Mover



This project was entered in the LSAA 2009 Design Awards (Cat 2, #2066)

Entrant: Tensys Engineers Pty Ltd
Location: Las Vegas, USA

The tensile fabric roof (approximately 10,000 sq ft) each covers the APM station at Monte Carlo and Bellagio Casino/Resort.  The APM stations are part of the US7 billion dollar development in Las Vegas (designed by Gensler LA) due for opening in various stages the end of 2009.

LSAADA2009Cat2528
LSAADA2009Cat2532
LSAADA2009Cat2533
LSAADA2009Cat2531
LSAADA2009Cat2529
LSAADA2009Cat2530

Mildura Riverfront Performance Venue
Mildura Riverfront Performance Venue

This project was entered in the LSAA 2009 Design Awards (Cat 2, 2397)

Entrant: Oasis Tension Structures (Australia) Pty Ltd
Location: Hugh King Boulevard - Mildura VIC

Application: This large PVC structure was created to provide a spectacular shelter from which entertainment of all descriptions can operate under cover in the picturesque environment of the banks of the Murray River in Mildura.

LSAADA2009Cat2540
LSAADA2009Cat2538
LSAADA2009Cat2539
LSAADA2009Cat2537
LSAADA2009Cat2546
LSAADA2009Cat2545
LSAADA2009Cat2544
LSAADA2009Cat2543
LSAADA2009Cat2542
LSAADA2009Cat2541

Al Raheeb Kindergarten UAE
Al Raheeb Kindergarten UAE



Entrant: Structurflex Ltd

Client: Dubai Municipality   Structural Engineer: Wade Consulting Group
Builder: Mazroui General Contracting   Fabricator(s): Structurflex Ltd

This project was entered in the LSAA 2007 Design Awards (Medium Structures, #2022)

Application: Provide a simple ascetically pleasing structure over the courtyard of a kindergarten. The small awnings around the perimeter to provide shade in the classrooms.

LSAADA20072022e
LSAADA20072022d
LSAADA20072022c
LSAADA20072022b
LSAADA20072022a
LSAADA20072022-Render
LSAADA20072022l
LSAADA20072022k
LSAADA20072022j
LSAADA20072022i
LSAADA20072022h
LSAADA20072022f
LSAADA20072022g

John Street Bridge - Whangarei, NZ
John Street Bridge - Whangarei, NZ



This project was entered in the LSAA 2011 Design Awards (Cat 2, 2321)

APPLICATION: Public space & market canopy

As part of a major revitalisation and landscaping project for the Whangarei City Town Basin, the local council approached FSS to design a permanent canopy structure for the recently closed John Street bridge.

The John Street Bridge was one of two original road bridges connecting the Northern and Southern shores of the upper Whangarei harbour and forms part of the City Town Basin.

LSAA2011DA232101
LSAA2011DA232100
LSAA2011DA232111
LSAA2011DA232110
LSAA2011DA232109
LSAA2011DA232108
LSAA2011DA232106
LSAA2011DA232107
LSAA2011DA232105
LSAA2011DA232104
LSAA2011DA232103
LSAA2011DA232102

Pacific Fair Entrance
Pacific Fair Porte Cochere



This project was entered into the LSAA 2016 Design Awards Category 2 (Medium Fabric Structures # 2114)

Entrant: Fabritecture (Designer and Installer)

Location: Broadbeach, QLD.   Completed: Feb 29 2016

Client: Scentre Group (Westfield)

Team: Scentre Group (Westfield), Wade Design, Fabritecture, Textile Fabrication Services, Fabritecture

Application

A spectacular feature porte cochere architectural fabric structure for the main entry point of the new Pacific Fair Shopping Centre.

LSAADA2016Cat20153
LSAADA2016Cat20152
LSAADA2016Cat20151
LSAADA2016Cat20150
LSAADA2016Cat20149
LSAADA2016Cat20148
LSAADA2016Cat20147
LSAADA2016Cat20146
LSAADA2016Cat20145
LSAADA2016Cat20144
LSAADA2016Cat20143
LSAADA2016Cat20140
LSAADA2016Cat20139
LSAADA2016Cat20138
LSAADA2016Cat20137
LSAADA2016Cat20136
LSAADA2016Cat20134
LSAADA2016Cat20135

Green School Pods, New Plymouth, NZ
2374 Green School Pods - New Plymouth, NZ

LSAA 2022 Plaques 0010

APPLICATION OF PROJECT:

3 Pod like classrooms at Green School NZ

PROJECT DESCRIPTION:

To provide an outer skin from a material that can be recycled if/when replaced and also blends into environment.  Wastage of non-recyclable materials to be kept to a minimum.

Also to provide the support frame to take the PVC membrane.

DESIGN / FABRICATION / INSTALLATION BRIEF

It was requested by the architect that we would supply a membrane solution for three-pod like classrooms for Green School New Zealand, to function as an aesthetic cladding and to create a ventilated thermal barrier to reduce a “heat soak effect” into the building.  This was to complement the “green” label for the structure, reducing running costs and adding an organic look.

STRUCTURAL SYSTEMS

The overall complexity of the project was caused by the intriguing shape and challenging geometry, also the construction materials which were proposed.

The glulam timber beams implicated large tolerances on site, which required the steel components to be customized to match each of the three structures.

3d- digitizing of the design assisted by the construction of the tension-membranes.  The high stretch of the fabric paired with the shape of the structures added the additional complexity of staged tensioning over multiple weeks.

MATERIALS

Mehler – Valmex Lodge de lux FR – 580gsm PVC

FABRICATION

The fabrication had complex geometry as the fabric had a high weft compensation which meant minimum tolerance to allow for the correct fit. The geometry for the fabric started with digital site measure using a Proliner first, followed by computer controlled cutting many checks and keder length dimensions to ensure accurate final panel size.

A similar process was used for the steel fabrication given the challenging geometry.

COLLABORATION, CONSTRUCTION AND MAINTENANCE

Being a bespoke membrane structure Cleland Construction Limited had to overcome the different approach from standard construction methodology and Fabric Structures & Cleland Construction work well to get the desired effect. This was mainly around a realization that fabrication off a 3D model was not going to create a successful outcome, therefore a proliner measure once the steel had been installed, then fabrication (with multiple QA check s) was agreed.

COSTS

Design – 12%   Fabric – 6%   Fabrication – 6%     Steel – 50%     Extrusion etc – 4%  Installation – 22%

PROJECT CREDITS

Project Name  Green School New Zealand
Location       406 Koru Road, Koru
City    New Plymouth
Country        New Zealand, 4374
Completion Date     Oct-20
Category 2    Medium structures – 250m2 – 1000m2
Entrant Name         Fabric Structures Limited
Address:       141 Dent Street,
Suburb:        Central Business, Whangarei
Country:       New Zealand, 0110
Telephone Land line:         +64 9 4388343
Mobile:         +64 275276452
Email Address:        This email address is being protected from spambots. You need JavaScript enabled to view it.
Website address:     www.fabricstructure.co.nz
Entrant Type / Role Designer / Fabricator / Installer
Project Client:         Green School
Project Architect:    Glen Brebner, Milca Severo, Boon
Structural Engineer: Fabspan/XiangDu
Specialist Consultant & Role:       Kayne Jacobson, Project Manager
Building Contractor: Cleland Construction Limited
Fabricator(s): Fabric Structures Ltd – for membrane fabric
Others:         Meco Engineering Co for Steel (under FSL contract)

Blacktown Village Green
Blacktown Village Green



This project was entered in the LSAA 2011 Design Awards (#7007)

PROJECT DESCRIPTION

This project was essentially a weather cover over a public space. During discussions with our sales team at the tendering stage it was clear that the project also had an element of environmental consideration. For this reason we developed a custom design that worked to these constraints.

The purpose according to builders was to create an inviting public recreation area. The architects specified a tensile membrane roof in order to cover the area while allowing natural light to enter the space.

LSAA2011DA700703
LSAA2011DA700711
LSAA2011DA700710
LSAA2011DA700708
LSAA2011DA700707
LSAA2011DA700706
LSAA2011DA700705
LSAA2011DA700704
LSAA2011DA700702
LSAA2011DA700701

Elizabeth Quay Project
Elizabeth Quay



This project was entered into the LSAA 2016 Design Awards (Category 2, Entry 2063)

Entrant: Fabritecture (Designer and Installer)

Location: The Esplanade.   Completed: August 20 2015

Client: Leightons

Team: ARM Architects, Maffeis Engineering, Fabritecture, Seele, Fabritecture

Application

A unique ferry terminal structure utilising custom ETFE cushion system paired with aluminium cladding as part of the Elizabeth Quay upgrade development in the Perth CBD.

LSAADA2016Cat20116
LSAADA2016Cat20115
LSAADA2016Cat20114
LSAADA2016Cat20133
LSAADA2016Cat20132
LSAADA2016Cat20131
LSAADA2016Cat20130
LSAADA2016Cat20129
LSAADA2016Cat20128
LSAADA2016Cat20127
LSAADA2016Cat20126
LSAADA2016Cat20125
LSAADA2016Cat20124
LSAADA2016Cat20123
LSAADA2016Cat20122
LSAADA2016Cat20121
LSAADA2016Cat20120
LSAADA2016Cat20119
LSAADA2016Cat20117
LSAADA2016Cat20118

Knox Grammar School
Knox Grammar School Project (2018)

APPLICATION OF PROJECT:

The project was to design and install a unique waterproof shade structure to a Year 11/12 study area at an elite private Grammar School in Sydney.

The area under cover is 760sqm. The space to be shaded was clearly defined and located between the austere 19th century red brick buildings on a second floor flat tiled roof

PROJECT DESCRIPTION:

Beyond a school’s playing fields, exposed concrete surfaces often represented the extent of outdoor space in many schools built a century ago. Knox Grammar was no different.Today the definition of outdoor space is much more exciting and open to design possibilities. For schools with resources, outdoor spaces can be unique, comfortable, multifunctional and aesthetic.

20707
20706
20705
20704
20703
20701
20702

Isa Royal Military College Grand Stand
Isa Royal Military College Grand Stand



Entrant: Light Weight Structures Advisory Service - Engineering Fabrication Installation
Location: Isa Royal Military College - Kingdom of Bahrain
Client:  Alasco Group & Al Alaa Shade Company
Struct. Eng.: Trevor Scott & Jeremy Hunter
Specialist: LTWSAS
Builder & Fabricator: Al Alaa Shade Company

This project was entered in the LSAA 2009 Design Awards (Cat 2, Medium Fabric Structures #24558)

No further details have been entered at this stage

LSAADA20092455806
LSAADA20092455815
LSAADA20092455813
LSAADA20092455814
LSAADA20092455812
LSAADA20092455811
LSAADA20092455810
LSAADA20092455809
LSAADA20092455807
LSAADA20092455808

Verandah Cafe - Hamilton New Zealand
Verandah Cafe at Hamilton NZ



Entrant: Structurflex Ltd - Engineering Fabrication Installation
Location: Hamilton Lake Domain
Client: Hamilton City Council
Architect: 360 Architects
Struct. Eng.: Compusoft Engineering
Builder: Foster Construction
Fabricator: Structurflex

This project was entered in the LSAA 2009 Design Awards - Medium Structures (#2022)

No further details have been entered to date.

LSAADA2009Cat2527
LSAADA2009Cat2526
LSAADA2009Cat2525
LSAADA2009Cat2524
LSAADA2009Cat2523
LSAADA2009Cat2522
LSAADA2009Cat2521
LSAADA2009Cat2520

Point Boston Peninsular Club
Point Boston Peninsular Club



Entrant: MakMax Australia - Designer
Location: Port Lincoln South Australia
Client: Kym Clarke Constructions
Architect: John Diekman Architects
Struct. Eng.: MakMax Australia
Others: Cost Management Partners
Builder: Kym Clarke Constructions
Fabricator: MakMax Australia

This project was entered in the LSAA 2009 Design Awards (Cat2, Medium Fabric Structures #2813)

No further details have been entered to date.

LSAADA2009Cat2550
LSAADA2009Cat2551
LSAADA2009Cat2548
LSAADA2009Cat2549
LSAADA2009Cat2547
LSAADA2009Cat2556
LSAADA2009Cat2555
LSAADA2009Cat2554
LSAADA2009Cat2552
LSAADA2009Cat2553


Laneways Canopy Whangarei, New Zealand
Laneways Canopy Whangarei, New Zealand



This project was entered in the LSAA 2016 Design Awards (Cat 2 Medium Structures, 2047)

Entrant: Fabric Structure Systems (Designer / Fabricator / Installer)

Location: Whangarei, New Zealand.   Completed: April 2016

Client: Whangarei District Council

Team: Wade Design Engineers Ltd, Fabric Structure Systems, Culum Engineering (Steel)

Application

To enhance the CBD environment and aid in the rejuvenation of the central business district to encourage the return of pedestrian traffic therefore enhancing the shopping experience.

LSAADA2016Cat20109
LSAADA2016Cat20108
LSAADA2016Cat20113
LSAADA2016Cat20112
LSAADA2016Cat20110
LSAADA2016Cat20111

Description

A local council initiative to revitalise the existing town center mall. The new canopy to be an integral feature of the ‘ shared space’ pedestrianizing of the dated 40 year old mall.

Penguin Parade Phillip Island
Penguin Parade Phillip Island



This project was entered in the LSAA 2011 Design Awards (Cat 2, 2600)

Entrant: Tensys Engineers

Aside from the images below, no further details have been entered at this stage.

This is a replacement structure for the one built in 1989 that was damaged in a storm

LSAA2011DA260003
LSAA2011DA260004
LSAA2011DA260002
LSAA2011DA260001
LSAA2011DA260000
LSAA2011DA260009
LSAA2011DA260008
LSAA2011DA260007
LSAA2011DA260006
LSAA2011DA260005



Catholic College - Bendigo
Catholic College Bendigo



This project was entered in the LSAA 2016 Design Awards  - (Cat2, 2697)

Entrant: Structureflex (Designer / Engineer)

Location: Junortoun, Bendigo.   Completed: December 2015

Client: Catholic College Bendigo

Team: Y2 Architects, Steve Huppert, John Killmister (Cert. Eng), Shade Living Pty Ltd, Glarfab (membranes), Thornton Engineering (steel)

 Application

A large asphalt courtyard area was upgraded to provide a focal point for the students for play and school functions.

LSAADA2016Cat20156
LSAADA2016Cat20159
LSAADA2016Cat20158
LSAADA2016Cat20157
LSAADA2016Cat20155
LSAADA2016Cat20154

La Piazza - Jakarta
La Piazza - Jakarta



Entered in the LSAA 2007 Design Awards (Cat 2, #2007, Medium Fabric Structures)

Entrant: PT Binatama Akrindo
Client: PT Summarecon Agung Tbk.
Unit La Piazza
Architect: PT Binatama Akrindo Sarjono Sam
Structural Engineer: PT Binatama Akrindo Tensys
Builder: PT Binatama Akrindo
Fabricator(s): Atkins Fabrications Pty Ltd,
PT Binatama Akrindo - Tridome space frame system + steelwork

Application: Lightweight Roof Canopy Over Café and Exhibition Stage

LSAADA2007Cat2183
LSAADA2007Cat2186
LSAADA2007Cat2185
LSAADA2007Cat2184
LSAADA2007Cat2182
LSAADA2007Cat2181
LSAADA2007Cat2180
LSAADA2007Cat2179
LSAADA2007Cat2178
LSAADA2007Cat2177
LSAADA2007Cat2187

Finished-Shore-Pool-Skylight 1
Shore School Pool Hall Skylight (DA 2022 Entry by MakMax)

LSAA 2022 Plaques 0006
APPLICATION OF PROJECT
:

ETFE 600 sqm Skylight over an indoor swimming pool

PROJECT DESCRIPTION:

The Shore Physical Education Centre (SPEC) was built to deliver a suite of new flexible learning spaces including a multi-purpose sports complex and an indoor swimming pool. The 16 pillow, 3-layer ETFE skylights were a key part of the indoor swimming pool roof, designed to fill the indoor aquatic centre with natural lighting, while also providing a modern, highly aesthetic architectural feature to the roof.

DESIGN / FABRICATION / INSTALLATION BRIEF

The ETFE skylights located over the indoor swimming pool in the new Shore Physical Education Centre (SPEC) were required to interface with the surrounding Kingspan insulated roof system. We worked closely with the project Architect, Structural Engineer and Builder to develop design details that allowed the two elements to seamlessly connect.

Hiding of ductwork and the air supply plenum was important to the overall finish and as part of our value engineering approach to design, we proposed unique design touches, such as painting the air supply lines to match the internal fascia and keeping the ductwork hidden adjacent to structural elements in order to keep the premium-quality project finish required by the project brief.

Halo Night Club Brisbane
Halo Night Club Brisbane



Entrant: Fabritecture

Location: Brisbane
Client: AGS Construction
Completion Date: February 2012

This project was entered in the LSAA 2013 Design Awards (Cat 2, 2301)

PROJECT DESCRIPTION:

Halo was designed to take full advantage of Brisbane's wonderful weather offering a sophisticated, open-air lounge environment. In the trendy suburb of Paddington on the West Side of Brisbane is the Caxton Street Precinct famous for its entertainment venues and bustling nightlife.

23012A
230111
23019
23013

Sydney Aquarium Dugong's at Mermaid Lagoon
Sydney Aquarium Dugong's at Mermaid Lagoon



Sydney Aquarium Dugong's at Mermaid Lagoon

This Project was entered into the LSAA 2009 Design Awards (29047)

Entrant: UFS Australasia Pty Ltd - Designer / Fabricator
Location: Sydney Aquarium - Darling Harbour Sydney
Client: Sydney Attractions Group
Struct. Eng.: Wade Consulting
Builder: Universal Fabric Structures / Ozrig
Fabricator: Fabric Shelter Systems

No further details have been entered.



LSAADA20092904704
LSAADA20092904703
LSAADA20092904701
LSAADA20092904702


Hornsby Aquatic Seating Covered Areas
Hornsby Aquatic Seating Covered Areas



This project was entered in the LSAA 2016 Design Awards (Cat 2, Medium Fabric Structures 1293)

Entrant: Shade And Membrane Structures Australia (Design / Project Management / Install)

Location: Hornsby, NSW.   Completed: April 30 2014

Client: ADCO Constructions / Hornsby City Council

Team: Peter Hunt Architects, Larry Shyu Global Membrane Design, ADCO Constructions, Shadecom / Fabric Solutions

Application: To design, engineer, fabricate and install approximately 400 sqm of waterproof shade structures to cover two seating areas.

LSAADA2016Cat20079
LSAADA2016Cat20077
LSAADA2016Cat20076
LSAADA2016Cat20075
LSAADA2016Cat20074
LSAADA2016Cat20073
LSAADA2016Cat20072
LSAADA2016Cat20071
LSAADA2016Cat20070
LSAADA2016Cat20069
LSAADA2016Cat20068
LSAADA2016Cat20086
LSAADA2016Cat20085
LSAADA2016Cat20084
LSAADA2016Cat20083
LSAADA2016Cat20082
LSAADA2016Cat20081
LSAADA2016Cat20080
LSAADA2016Cat20078

Description:

Working closely with the council, their architects, the builders and the engineers for over 18 months we were able to come up with a design that suited both the architectural and practical intent. With the centre opening in July 2014, the council are extremely pleased with the outcome. We were basically asked to cover the seating areas of two sides of the pool to provide both cover and international water polo standard lighting to the pool area.

Panned side shot of the Rady Shell (photo credit: San Diego Symphony)
Rady Shell - San Diego (2021 DA Entry)

LSAA 2022 Plaques 0004APPLICATION OF PROJECT

Outdoor concert theatre at Jacobs Park

The Rady Shell Concert Venue Description

The Rady Shell in San Diego Symphony’s new bay side venue is the first permanent year-round bay side concert venue in the nation operated by the Symphony Orchestra. The Rady Shell can accommodate audiences of 3,500 – 8,000 per concert and up to 10,000 for special events.

Fabritecture was engaged for the technical design and fabrication of the Rady Shell performance structure and surrounding pavilion structures. The Shell itself comprises a rolled steel frame and PTFE cladding. The entire structure is approximately 236,000lbs (107,000kgs or 107 tonnes).

The stage accommodates an orchestra size of up to 150 musicians and choir with a front of stage width of 32m and depth of 20m. The roof cantilevers 15m from the front of the stage and can carry a payload of up to 50T. The stage incorporates state of the art constellation sound system designed and engineered by Meyer Sound. This system provides an exemplary sound environment on stage for the musicians, whilst also providing the technical flexibility required for a variety of other performances

The overall project includes development of a range of public facilities, including restrooms, fitness facilities & rest areas. Food pavilions and a small stage are also part of the master design plan.

Ocean Supercenter
Ocean Supercenter



This project was entered into the LSAA 2016 Design Awards (Cat 2 Medium Structures #72)

Entrant: GeoMetal Limited (Design & Engineering)

Location: Ocean Supercenter, Myanmar, Thailand.   Completed: January 2016

Client: Capital Properties

Team: Process Architect & Planner Co., Ltd., Fastech Company Limited

Application: Signature Structure at a shopping Mall

LSAADA2016C27214
LSAADA2016C27219
LSAADA2016C27213
LSAADA2016C27217
LSAADA2016C27218
LSAADA2016C27215
LSAADA2016C27216

General shot of structures
General shot of shade structures

M6 Community Recreational Facility Description

As part of Transport NSWs upgrade to the M6 freeway Stage 1 development, new recreational facilities were developed to provide shade to the community in various areas including McCarthy and Brighton Reserve. As part of the McCarthy Reserve upgrade, Fabritecture was contracted for the design and construction of eight (8) structures to provide shade cover for recreational facilities over a playground. The structures feature both Gale Pacific 95 Mesh and architecturally perforated aluminium.

DESIGN / FABRICATION / INSTALLATION BRIEF

Transport for NSW is delivering new recreational facilities for the Bayside Community before construction begins on Stage 1 of the M6 motorway in Rockdale, NSW. Fabritecture was contracted for 8 structures for installation at McCarthy Reserve. The structures are a combination of mesh shade structures clad with Gale Pacific Commercial 95 Heavy shade cloth, and aluminum architectural metal structures with custom artwork perforations in the panels.

216301
216302
216303
216304
216305
216306
216307
216308
216309

STRUCTURAL SYSTEMS

The aluminium structures feature a steel frame with a grid system for the aluminium. The perforated panels are underslung, so the custom perforated artwork can be seen clearly from underneath the structures in the playground.

The shade structures are also steel framed and are tensioned using a Fabritecture extrusion system.

MATERIALS

The chosen material for the shade structures was Gale Pacific Commercial 95 340 Mesh, in 4 colours: Aquatic Blue, Desert Sand, Yellow and Orange. The fabric was chosen based on the colour specifications from the client.

The aluminium panels for the architectural metal structures was 6mm thick with a Colourbond Monument equivalent RAL 7021 with custom artwork perforations.

FABRICATION

The aluminium artwork features custom perforations in the patterning of native flora such as bottlebrush, and flora such as birds and frogs. There are 6 mesh structures in total at McCarthy Reserve, with 4 having an 8m diameter, and 2 with an 11m diameter. The 2 aluminium structures are 11m and 17m in diameter.

COLLABORATION, CONSTRUCTION AND MAINTENANCE

The installation of the structures occurred over existing playground equipment. This required specific planning. Construction involved the installation of all columns first and preassembling of roof discs on the ground. These were then crane lifted into their final install position. There was no overhead install.

Gale Pacific Commercial 95 340 Mesh is used widely for projects that require maximum sun protection and strength. The durable mesh fabric has low maintenance requirements and a long life performance.

COSTS

The M6 Community Recreational Facility project was valued at approximately AUD$730k.


PROJECT CREDITS

Project Name: M6 Community Recreational Facility
Location: West Botany Street
City: Rockdale, NSW, 2216
GPS Location:   -33.955663, 151.146580
Completion Date: 12-Oct-21
Category (1-8): 2 – Medium structures
Entrant Name: Fabritecture
Address:  Unit 14/15 John Duncan Court, Varsity Lakes, QLD 4227
Telephone:   +61 7 5587 7000
Mobile:   +61 408 402 716
Email Address:  This email address is being protected from spambots. You need JavaScript enabled to view it.
Website Address: www.fabritecture.com
Entrant Type / Role: Designer / Fabricator / Installer
Project Client: Transport NSW
Project Architect: Design Inc.
Structural Engineer: Greenup Design Engineers; Cardno
Building Contractor: Ertech Pty Ltd
Fabricator(S): Confidential
